BOMGE U404 USB Audio Interface — 4-In/4-Out, 24-bit/192kHz, 48V & MIDI

The BOMGE U404 is a four-channel desktop audio interface for bands, home studios and podcast setups that have outgrown a 2-input box. Four combo inputs take microphones, guitars, keyboards or line-level gear at the same time, and each one records to its own track on your computer. Four separate XLR outputs, a 5-pin MIDI port and an XMOS USB chip with BOMGE's own ASIO driver round it out in a metal chassis.

Highlights

• True 4-in / 4-out: four independent input tracks and four independent outputs, routable in the driver's control panel
• 4 combo XLR/6.35mm inputs, each with its own Line/Inst switch, gain knob and clip/signal LEDs
• +48V phantom power for condenser microphones (one switch on the rear panel)
• Direct Monitor button for zero-latency monitoring, plus a 6.35mm headphone output with its own level knob
• MIDI In/Out (5-pin DIN) for keyboards and hardware synths
• XMOS audio processor + ASIO low-latency driver with a routing/status control panel
• Works with Mac and Windows DAWs such as Ableton Live, Pro Tools and Cubase
• Dedicated 5V/2A USB-C power socket: run it from a phone charger, power bank or computer

Specifications

• Model: BOMGE U404
• Configuration: 4 inputs / 4 outputs
• Resolution: 24-bit / 192kHz
• Inputs: 4 × combo XLR / 6.35mm jack (mic, line or instrument)
• Outputs: 4 × XLR (rear panel)
• Headphone output: 6.35mm with independent volume
• Front controls: 4 × gain, 4 × Line/Inst switch, Direct Monitor, main output level, headphone level
• Phantom power: +48V, rear on/off switch
• MIDI: 5-pin DIN In and Out
• Computer connection: USB-C (USB 2.0)
• Power: 5V/2A DC via separate USB-C power socket
• Processor/driver: XMOS chip, BOMGE ASIO driver
• Chassis: metal
• Dimensions: 30.5 × 11.3 × 5.5 cm

Gain range, input impedance, dynamic range and weight are not published by the manufacturer.
